OneDrive Connector

Configuring SearchBlox

Before using OneDrive Connector, install SearchBlox successfully and create a Custom Collection.

**Configure Onedrive App for Onedrive connector

  • Click on Add an app after successful login
  • Specify application name and click on create
  • Note down application id
  • click on add platform
  • Click on WEB
  • Specify redirect URL and click on save

OneDrive Connector

  • All the files related to the connector should be available in the same folder i.e., all files should be extracted into the same folder.
  • Create a data folder on your drive where the files would be temporarily stored and mention in yml files.

Contact support@searchblox.com to request the download link for SearchBlox OneDrive connector. The steps below include the example paths for both Windows as well as Linux. In Windows, the connector would be installed in the C drive.

Steps to Configure OneDrive Connector

  • Download the SearchBlox OndDrive connector. Extract the downloaded zip to a folder.
  • Unzip the archive under C:\
  • Configure the onedrive.yml file which includes OneDrive properties and SearchBlox properties as listed below:

data-directory

Data Folder where the data needs to be stored. Make sure it has write permission.

api-key

SearchBlox API Key

colname

The name of the custom collection in SearchBlox.

url

SearchBlox URL

exclude-folders

Folders to exclude in OneDrive.

log-file-maxSize,log-file-maxBackups,log-file-maxAge

megabytes after which new file is created
number of backups after which log file should be deleted
Number of days after which log files should be deleted

servlet url & delete-api-url:

Make sure that the port number is right. If your SearchBlox runs in 8080 port the URLs should be right.

authURL

OneDrive authorization url
default: https://login.live.com/oauth20_authorize.srf

tokenURL

OneDrive api token url
default: https://login.live.com/oauth20_token.srf

redirectUrl

OneDrive redirect uri to redirect back to Goconnector. Please be careful about port when specifying, it should not be same as SearchBlox port.

clientId

OneDrive app client id

clientSecret

OneDrive app client secret

port

OneDrive GOconnector port, should have the same port number given in redirect url

api_url

OneDrive API url
default: https://api.onedrive.com/v1.0/

  • The content details of onedrive.yml are provided below:
#SearchBlox API Key
api-key: 930B1FDD47479694D9B197615FC779E0
#The name of the collection
colname: onedrive
#SearchBlox URL
url: http://localhost:8080/searchblox/rest/v2/api/
#Data Folder where the data needs to be stored Make sure it has write permission
data-directory: C:/onedrive/data
#megabytes after which new file is created
log-file-maxSize: 10
#number of backups after which log file should be deleted
log-file-maxBackups: 10
#Number of days after which log files should be deleted
log-file-maxAge: 30
#The Excluded folders wont be indexed. Note:no trailing or leading slashes Eg: test/searchblox
exclude-folders: [connector]
#searchblox servlet url for auto delete functionality
servlet-url: http://localhost:8080/searchblox/servlet/SearchServlet
#searchblox delete api url for auto delete functionality
delete-api-url: http://localhost:8080/searchblox/api/rest/docdelete
#onedrive authorization url
authURL: https://login.live.com/oauth20_authorize.srf
#onedrive api token url
tokenURL: https://login.live.com/oauth20_token.srf
#onedrive redirect uri to redirect back to Goconnector,Be careful about port when specifying
redirectUrl: http://localhost:8081/handle
#onedrive app client id
clientId: 4fe024fe-9ab4-43dd7d-b34b-66703fd8a11427
#onedrive app client secret
clientSecret: eftPUK9529jqddfdbsGBJK4!)_+
#one drive GOconnector port,Should be same as port number in redirect url
port: 8081
#one drive connector API url
api_url: https://api.onedrive.com/v1.0/
  • Start running the onedriveConnector.exe file for Windows
